※ Because the mixing barrel moves in multiple directions, there is no centrifugal force acting on the materials, as well as no phenomena of gravity segregation, lamination and accumulation of materials so that the mixing rate can be up to 99.9%
※ The barrel has high loading rate (max.80 percent, however, only 40 percent for the conventional mixers), so that it features high efficient and short mixing time.
※ The barrel transitional radius everywhere, conform GMP
|
specification |
HD-1 |
HD-5 |
HD-15 |
HD-50 |
HD-100 |
HD-200 |
HD-400 |
HD-600 |
HD-800 |
HD-1000 |
|
Barrel volume( L ) |
1 |
5 |
15 |
50 |
100 |
200 |
400 |
600 |
800 |
1000 |
|
Max loading volume( L ) |
0.8 |
4 |
12 |
40 |
80 |
160 |
320 |
480 |
640 |
800 |
|
Max loading capacity( kg ) |
0.5 |
2.4 |
7.5 |
25 |
50 |
100 |
200 |
300 |
400 |
600 |
|
rotating speed of driving shaft (r/m ) |
15-30 |
8-15 |
||||||||
|
power of motor( kw ) |
0.12 |
0.25 |
0.37 |
1.1 |
1.5 |
2.2 |
4 |
5.5 |
7.5 |
7.5 |
|
Overall dimensions |
500× 600× 600 |
600× 1000× 1000 |
700× 1000× 1000 |
1000× 1400× 1200 |
1200× 1700× 1500 |
1400× 1800× 1600 |
1800× 2100× 1950 |
1900× 2100× 2250 |
2200× 2400× 2300 |
2250× 2600× 2300 |
