※ The machine adopts horizontal barrel(cone) structure. Its structure is reasonable.
※ The inner surface of equipment has no dead corner. It works at sealed state and conforms to the requirements of cGMP.
※ Short granulating time, high efficiency and energy saving
※ The character of granule is uniform and the fluidization of granule is good. It provides ideal granule material for tablet pressing procedure.
※ Compare with traditional process, it can reduce 25% of binder and shorten drying time too.
※ Each batch needs 2 minutes to dry mixing and 1 ~ 4 minutes to granulating. Compared with traditional process, its efficiency can raise 4 ~ 5 times.
※ Whole operation has strict safe protective measures
|
Specification |
GHL-10 |
GHL-50 |
GHL-150 |
GHL-200 |
GHL-250 |
GH-L300 |
GH-L400 |
GHL-600 |
800~1200 |
|
|
Item |
||||||||||
|
Container voiume |
L |
10 |
50 |
150 |
200 |
250 |
300 |
400 |
600 |
By client |
|
Capacity |
kg/batch |
3 |
15 |
50 |
60 |
80 |
100 |
135 |
200 |
|
|
Mixing speed |
r.p.m |
300/600 |
200/400 |
180/270 |
180/270 |
180/270 |
140/220 |
106/155 |
80/120 |
|
|
Mixing power |
kw |
1.2/2.2 |
4/5.5 |
6.5/8 |
9/11 |
9/11 |
13/16 |
18.5/22 |
22/30 |
|
|
Cutting speed |
r.p.m |
1500/3000 |
||||||||
|
Cutting power |
kw |
0.85/1.1 |
1.3/1.8 |
2.4/3 |
4.5/5.5 |
4.5/5.5 |
4.5/5.5 |
6.5/8 |
9/11 |
|
|
Size of installation for reference |
A(mm) |
1350 |
1650 |
1750 |
2050 |
2050 |
2200 |
2350 |
2400 |
|
|
B(mm) |
1050 |
1250 |
1300 |
1400 |
1400 |
1450 |
1450 |
1550 |
||
|
C×D(mm) |
1000×650 |
1250×800 |
1350×800 |
1650×850 |
1650× |
1700× |
1860× |
2000× |
||
|
850 |
900 |
1050 |
1050 |
|||||||
